Brass-Backed Hammer Union Seals for FIG 602 and FIG 1002
Royal Way® brass-backed hammer union seal enquiries are matched to the specific FIG 602 or FIG 1002 assembly drawing. Specify the elastomer compound, brass component geometry and union manufacturer together. Confirm whether the order covers the complete specified construction or individual replacement parts.
The brass-backed construction must be reviewed with the union seal pocket and operating conditions. Provide fluid composition, temperature and pressure cycling for compound and assembly review. A metal backing description alone does not establish a pressure rating, leak-free performance or compatibility with another union figure.
Specify the Brass Component and Elastomer as One Defined Construction
Supply the seal drawing showing the brass part, elastomer profile and their relative position in the union pocket. Include brass material requirements, dimensions and tolerances where specified. State whether the metal component is integrated with the seal or supplied separately according to the approved design.
Identify the union manufacturer, FIG 602 or FIG 1002 designation, nominal size and part number. Confirm the elastomer compound and nominal hardness with tolerance. Where HNBR or FKM is requested, provide the actual fluid and temperature requirements; gas or sour-service use needs specific qualification.
Agree dimensional inspection and assembly test requirements for the brass-backed replacement. Confirm which components are included in the quotation and whether existing metal parts may be reused under the equipment maintenance procedure. Other figures and stainless anti-extrusion references retained below require separate part matching.
| 1" 1502, Buna / FKM/ HSN |
| 1-1/2" 1502, Buna / FKM / HSN |
| 2" 602/1502, Buna / FKM/ HSN(Brass/Stainless Anti-Ext) |
| 3" 602/1502, Buna / FKM / HSN(Brass/Stainless Anti-Ext) |
| 4" 602/1002/1502, Buna / FKM / HSN(Brass/Stainless Anti-Ext) |
| 2" FIG 206, Buna / FKM / HSN |
| 3" FIG 206, Buna / FKM / HSN |
| 4" FIG 206, Buna / FKM / HSN |
