Brass-Reinforced Hammer Union Seals for High Pressure Fig 602 1002 1502

Brass-Reinforced Hammer Union Seals for FIG 602, 1002 and 1502

Royal Way® brass-reinforced hammer union seals are specified by the complete seal construction and the corresponding FIG 602, 1002 or 1502 assembly drawing. Identify the union maker, nominal size, elastomer compound and brass reinforcement details for the replacement enquiry.

Review the brass reinforcement and rubber profile together with the seal pocket. Provide the operating fluid, temperature and pressure cycles for the selected construction. A brass-reinforced description does not establish a standalone pressure rating or interchangeability between union figures.

Product Specification

1. Pressure Selection: Specify the complete union rating and maximum service conditions. Confirm the reinforced seal against that assembly specification; FIG numbers alone are not seal pressure ratings.

2. Material Selection: Define the elastomer compound and brass material requirements. Include process fluid, cleaning agents and temperature exposure for compatibility review.

3. Replacement Fit: Check reinforcement dimensions, rubber profile and sealing surfaces against the drawing. Follow the equipment maintenance procedure and agree inspection and test requirements.

4. Reference Options: The table below retains the original union-size and material references. Select the brass-reinforced construction explicitly and distinguish it from stainless anti-extrusion options.

5. Service Verification: Define acceptance requirements for the assembled union. Gas or sour-service qualification must cover the specified compound and actual operating conditions.

Brass-Reinforced Seal Drawing and Replacement Acceptance

Provide a section drawing that identifies the brass reinforcement, rubber dimensions and locating features. Specify brass material, dimensional tolerances and any required finish. Confirm whether the construction is supplied as an integrated part or separate components according to the approved design.

For replacement approval, match FIG designation, union manufacturer and drawing revision before comparing samples. Define the elastomer nominal hardness and tolerance. Include the required checks for the metal and rubber portions together with the assembly test requirements.

Keep separate order lines for FIG 602, 1002 and 1502 constructions. Confirm whether the quoted item includes all specified reinforcement parts. Retained stainless and FIG 206 references below are separate options that require their own confirmed drawing and material selection.
