FKM PTFE Hammer Union Seal for High-Pressure Pipe Connections

Product Details:

Place of Origin:	China
Brand Name:	SHQN, Royal Way
Model Number:	Weco Fig 1502 1002 602

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	USD$1.5-4/PC
Packaging Details:	Carton Packing
Delivery Time:	7-21 days
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	5000pcs per month

Contact Now

Detailed Product Description

Product Name:	FKM And PTFE Hammer Union Seal Options	Material:	FKM And PTFE Options; Confirm Component Roles And Approved Construction
Color:	Customizable	MOQ:	1000PCS
Delivery Time:	7-15 Days	Sample:	Available
Service:	OEM/ODM	Feature:	Specified Material Compatibility And Complete Assembly Fit
Keyword:	FKM Hammer Union Seal, PTFE Union Ring, Pipe Connection Seal	Size:	Nominal Union Size By Enquiry; Component Dimensions By Drawing
Logo:	Customizable	Hardness:	FKM Nominal Hardness By Compound; PTFE Test Method By Grade
Highlight:	FKM PTFE hammer union seal , high-pressure pipe connection seal , hammer union seal with warranty

FKM and PTFE Hammer Union Seal Options for Pipe Connections

Name: FKM PTFE Hammer Union Seal for High-Pressure Pipe Connections
Brand: Shanghai Qinuo Industry Co., Ltd.
SKU: Weco Fig 1502 1002 602
Price: 2.50 USD
Availability: InStock

Royal Way^®FKM and PTFE hammer union seal enquiries are matched to the specified pipe connection and manufacturer drawing. Identify whether the required part is an FKM seal, a PTFE ring or a defined assembly using both materials. Confirm material grade, finished dimensions and operating requirements before replacement approval.

Confirm the Role of Each FKM or PTFE Component

Provide the complete union drawing, figure designation, manufacturer and nominal pipe size. Identify each seal or support component by part number and material. The FKM/PTFE listing does not by itself define a bonded, encapsulated or composite construction.

Specify the approved FKM compound or PTFE grade and any filler requirements for the relevant part. State fluid composition, cleaning exposure, temperature and pressure cycles. Service approval must cover the selected materials in the complete assembly.

Agree finished dimensions, tolerances and inspection requirements for each component. For FKM, define nominal elastomer hardness and tolerance; for PTFE, use the test method required by its grade specification. Confirm all included components with the order rather than assuming a general material list describes a complete kit.

Size:	1" 1.5" 2" 3" 4" 6" 7"
Material:	Buna/FKM/HNBR/PTFE
Types:	rubber/ rubber+brass back-up/rubber+ss back-up

FKM PTFE Hammer Union Seal for High-Pressure Pipe Connections

Material Introduction

Material name	Temperature range	Advantage	Deficiency
NBR(Buna)	NBR service temperature by approved compound Confirm operating exposure	1.Presently the most widely used rubber in the seal industry 2.Exceptional balance of good mechanical properties, wear properties, and chemical resistance 3.Resistance to most mineral oils and greases	don't used with gly-based brake fluids and strong acids
HNBR(Hydrogenated Nitrile)	HNBR service temperature by approved compound Confirm operating exposure	1.Chemical resistance 2.Wider temperature range than standard nitrile 3.High strength material that resists extrusion, abrasion, and wear 4.Water and steam exposure requires compound-specific review 5.H2S exposure requires specific compound qualification 6.Commonly used with petroleum oils and co2	don't use with chlorinated hydrocarbons, polar solvents, or strong acids
FKM(Fluorocarbon)	FKM service temperature by approved compound Confirm operating exposure	1.Excellent resistance to higher temperature, petroleum, and gasoline 2.Good chemical resistance, including to refrigerants(R12) 3.Great mechanical properties are retained over a wide temperature range 4.Ammonia exposure requires specific compound compatibility review	Check compatibility against the specific FKM formulation and complete fluid composition
PTFE (Polytetrafluoroethylene)	PTFE service temperature by grade and assembly Confirm operating exposure	Confirm compatibility for the selected PTFE grade and process fluid	Generally more expensive than other plastics or elastomers, which can be a limitation for cost-sensitive applications.
PU (Polyurethane)	PU service temperature by approved grade Confirm operating exposure	1.Thermoplastic elastomer with higher tensile strength, toughness, and wear resistance 2.Great combination of hardness and elasticity 3.Excellent low temperature flexibility 4.Commonly used in high pesure hydraulic systems where parts are subject to wear	Can degrade when exposed to UV light over prolonged periods unless specifically formulated with additives for protection.

Best Selling

FKM PTFE Hammer Union Seal for High-Pressure Pipe Connections

Company Profile

Shanghai Qinuo Industry Co., Ltd, established in 2013 within the Shanghai Free Trade Zone, is a pioneering high-tech enterprise specializing in the integration of research and development, production, and sales. Embracing the ethos of "Quality for Survival, Innovation for Development," we have garnered a stellar reputation domestically and internationally under the esteemed brand names of "Royal Way^®" and "SHQN^®".

FKM PTFE Hammer Union Seal for High-Pressure Pipe Connections

Mold Display	Rubber Workshop
Our workshop takes pride in producing a comprehensive range of molds, each designed to meet specific industry needs. We invite you to explore our range of customizable molds and discover how we can support your manufacturing needs with quality, precision, and innovation.	Different kinds of machines can fulfilled different requirement. Equip with advanced machinery and tools to handle various stages of rubber production, from mixing and extrusion to molding and vulcanization

Specializing in the design and production of professional rubber, plastic, and machining parts, our offerings cater to diverse industries such as oil and gas, automotive, household appliances, and machinery equipment. Our dedicated team adheres to the principles of "High-Quality, High Professionalism, High Efficiency" in all endeavors.
