Product Description:
Hammer union seals with brass backing are selected for matching union assemblies in oilfield flowlines. Specify the union figure, nominal size, seal profile and backing dimensions so the rubber sealing element and support ring match the assembly.
For a FIG 1502 seal-ring inquiry, provide the mating union drawing or approved sample. Confirm the brass backing construction and rubber compound separately; the presence of a metal support ring does not establish chemical compatibility or a pressure rating.
List the fluid or gas composition, operating temperature, pressure cycle and any gas-decompression or sour-service requirements. Qualify the compound and complete union assembly for the specified conditions before use.
Each Hammer Union Seal is carefully packaged in a carton box to ensure protection during storage and transportation. This packaging ensures that the seals remain in optimal condition until they are ready to be used, reducing the risk of damage and ensuring that they are ready for immediate installation.
For a brass-backed replacement, compare seal dimensions, backing location and compound specification with the original part. Agree sample fit and assembly testing before approving production.
Applications:
Royal Way hammer union seals can be requested for specified FIG 1502 or FIG 602 assemblies. Confirm each figure and size separately; one seal must not be assumed to fit both connection designs.
Royal Way operates under an ISO 9001 quality management system. Product suitability depends on the approved drawing, compound and assembly qualification; request applicable material and inspection documentation with the order.
For sizes within the listed 1-inch to 4-inch range, confirm the exact figure, profile and brass-backed design availability. Custom colors and logos can be specified for identification; color alone does not identify the rubber compound.
With a minimum order quantity of 100pcs and a competitive price range of $0.2 to $3 per piece EXW, these seals offer cost-effective sealing solutions without compromising on quality. Customers can choose between custom or standard packaging based on their preferences.
Orders are processed efficiently with a delivery time of 7-15 days, ensuring quick access to the product when needed. Payment methods including T/T and Paypal provide convenience and flexibility for customers worldwide.
Confirm production quantity and delivery schedule with the quotation. Assembly fit, compound compatibility and the specified functional checks must be reviewed for each ordered seal design.
Send the union identification, drawing or sample, required compound, brass backing dimensions and quantities for a matched quotation.
Brass Backing and Rubber Compound Order Requirements
Confirm whether the brass ring is supplied as part of a bonded seal or as a separate component. Provide the backing section, inside and outside diameters, seal lip profile and required material specification. Specify compound hardness and acceptance tests on the approved drawing. A brass-backed seal and an all-rubber seal require their own dimensional and service review.
Customization:
Product Customization Services for the Hammer Union Seal:
- Brand Name: Royal Way
- Model Number: Hammer Union Seals
- Place of Origin: Shanghai, China
- Certification: ISO9001
- Minimum Order Quantity: 100PCS
- Price: EXW$0.2/PC-$3/PC
- Packaging Details: Custom packing or standard packing
- Delivery Time: 7-15 days
- Payment Terms: T/T, Paypal
- Supply Ability: 50000pcs per week
- Type: Specify service conditions; sour-service suitability requires qualification
- Compatibility: Confirm compound against the specified fluid or gas and temperature
- Logo: Custom
- Color: Custom
- Cost-Effective: Affordable And Cost-effective Option
Keywords: Hammer Union Seals, Weco Seal Rings FKM, Brass Back up Seal Rings for Hammer Union
Packing and Shipping:
Product: Hammer Union Seal
Description: High-quality rubber seal for hammer unions
Package Includes: Confirm seal quantity and brass backing configuration with the order
Shipping Method: Standard Shipping
Shipping Cost: Confirm with destination, quantity and shipment method
