Weco Hammer Union Seals Coupling Seals With Brass / Stainless Steel Rings

Product Description:

Hammer Union Coupling Seals with Brass or Stainless Steel Back-up Rings


Hammer union seal rings are selected to match the connection drawing, seal profile and back-up ring arrangement. For replacement

connections, provide the union manufacturer, figure number, nominal size and existing seal dimensions. Dimensional tolerances must match the specified part,

rather than assuming that every seal with the same nominal connection size is interchangeable. Identify whether the assembly uses

an unreinforced rubber ring, a brass back-up ring or a stainless steel back-up ring. Include the metal grade and ring geometry where the drawing

specifies them. Inspect the mating surfaces and confirm installation requirements before selecting the replacement; a new seal alone does not establish the condition of the

complete union or its approved working-pressure rating.

Features:

• Product Name: Hammer Union Seal
• Back-up Ring Options: Brass or stainless steel, matched to the specified assembly
• Available Size: 1,1.5,2,3,4 Inch
• Payment Method: T/T, Paypal
• Shape: O Shape
• Application: Oil And Gas Industry
• FIG 1502 / Weco-type replacement inquiries: confirm exact manufacturer, part number and dimensions
• Made with NBR/FKM/HNBR materials
• Essential component for Hammer Union Seals

Technical Parameters:

Advantage:

High Pressure Tolerance: Confirm the working-pressure rating of the exact union assembly and its approved seal configuration. A figure number or seal material alone is not a pressure rating.

Temperature Resistance: Provide normal, peak and startup temperatures so the rubber compound and reinforced assembly can be reviewed together.

Chemical Compatibility: List process fluids, additives and cleaning chemicals when selecting both the elastomer and the brass or stainless steel component.

Durability: Inspect the seal seat and retaining surfaces, and follow the equipment maintenance requirements. Service life depends on operating conditions and assembly condition.

Versatility: Select the listed size and material family against the exact part drawing; nominal size does not establish interchangeability.

Brass vs Stainless Steel Back-up Rings: Specify the Complete Seal

Specify the rubber seal and metal back-up ring as one matched configuration. Send a drawing or sample identifying the ring position, inner and outer diameters, thickness and seal cross-section. A brass ring and a stainless steel ring should not be substituted solely because both fit the same nominal union size; confirm the approved material and dimensions for that connection.

For a quotation, include the union figure, manufacturer or part number, nominal size, seal compound, back-up ring material and quantity. State whether the metal ring is supplied separately or as part of the seal assembly. Include fluid composition, pressure cycles and temperature limits, and identify any sour-service qualification requirements.
