2 Inch FIG 602 Hammer Union Replacement Seal
Shanghai Qinuo supplies replacement-seal enquiries for 2 inch FIG 602 hammer union assemblies. Specify the original equipment drawing, seal-pocket dimensions and required NBR, HNBR or FKM compound before ordering. The 2 inch designation refers to the nominal union connection, not the measured seal OD or ID.
Product Specification
1. Pressure specification: Provide working pressure, transient peaks, temperature and pressure direction. The complete union assembly and selected seal design require qualification; a figure designation is not a standalone seal pressure rating.
2. Compound selection: Provide fluid composition, additives, cleaning chemicals and exposure duration. Review NBR, HNBR or FKM compound data against those conditions; polymer family alone does not establish chemical or sour-service suitability.
3. Installation fit: Confirm seal dimensions, lip orientation, mating surfaces and any brass or stainless steel backup ring against the equipment drawing. Follow the assembly installation procedure.
4. OEM dimensions: Send seal OD, ID, axial height, section profile and dimensional tolerances, together with nominal union size and figure. Include insert geometry and hardness where applicable.
5. Inspection requirements: Agree dimensional, material and leakage-test acceptance criteria for the selected design. Verify the complete assembly before service; no blanket pressure or leakage guarantee is implied.
2 Inch FIG 602 Seal Fit and Backup-Ring Confirmation
Identify the 2 inch FIG 602 union manufacturer drawing and part number. Provide seal OD, ID, axial height, lip geometry and mating-pocket dimensions. Specify rubber-only or brass/stainless steel backed construction according to the assembly design.
The existing table groups some 2 inch FIG 602 and FIG 1502 enquiries in one row. Confirm the individual seal drawing before substitution; a shared nominal size or table row does not establish interchangeable parts. FIG 206 O-ring entries are separate profile references.
Include fluid composition, temperature, pressure cycles, selected compound and hardness with the quantity. Confirm allowable operation and required tests for the complete union assembly. Manufacturing uses an ISO 9001 quality management system. For a replacement sample, check dimensions against the mating pocket because wear and compression can alter the old seal.
| 1" 1502, Buna / FKM/ HSN |
| 1-1/2" 1502, Buna / FKM/ HSN |
| 2" 602/1502, Buna / FKM/ HSN(Brass/Stainless Anti-Ext) |
| 3" 602/1502, Buna / FKM/ HSN(Brass/Stainless Anti-Ext) |
| 4" 602/1002/1502, Buna / FKM/ HSN(Brass/Stainless Anti-Ext) |
| 2" FIG 206, Buna / FKM/ HSN(AS568-228) |
| 3" FIG 206, Buna / FKM/ HSN(AS568-236) |
| 4" FIG 206, Buna / FKM/ HSN(AS568-346) |
