NBR, HNBR or Silicone Rubber O-Rings for Specified Hydraulic Grooves
Flexible Rubber O-Rings: Review Hardness, Installation Stretch and Groove Fit
| Installation check |
Information to review |
| Relaxed dimensions |
Inside diameter and cross-section with tolerances, or exact standard size reference. |
| Assembly route |
Largest feature the ring passes over, entry edges, threads and access to the groove. |
| Hardness and compound |
Target Shore A hardness and tolerance for the specified NBR, HNBR or silicone grade. |
| Installed fit |
Groove dimensions, specified squeeze and stretch, with clearance under operating load. |
| Operating duty |
Fluid, temperature, pressure cycle, motion and lubrication where applicable. |
Use the equipment assembly procedure and compatible installation lubricant. Protect the ring from sharp edges and twisting, and confirm seating before operation. Selecting a softer compound solely to ease assembly can change extrusion resistance; review hardness together with pressure and gland clearance.
Royal Way rubber O-ring enquiries in NBR, HNBR or silicone are specified with the mating groove, fluid and installation conditions. For applications where flexibility matters, define the target hardness and required assembly clearance. A softer feel does not establish the material grade or sealing performance; confirm the compound, dimensions and inspection requirements for the actual equipment.
|
Material
|
NBR, HNBR or silicone grade by fluid and installation requirements; other polymers reviewed separately.
|
|
Hardness
|
Original 20-90 Shore A range; agree target hardness and tolerance for the selected compound.
|
|
Feature
|
Flexibility and sealing performance depend on compound, hardness, dimensions and gland design.
|
|
Mode of Production
|
Compression, injection, injection transfer, extrusion, molding
|
|
Production Capabilities
|
Tooling, molding method and inspection criteria confirmed against the order drawing.
|
|
Size/Color
|
The size and color can be custom as customer’s requirements
|
|
Other Service
|
Customized drawing designs are welcome.Customized OEM products
|
Application of the rubber o ring:
For hydraulic and oilfield equipment, identify the installation route, fluid, temperature and pressure cycle. Include motion and lubrication for moving seals. Select the actual NBR, HNBR or silicone compound against these conditions; sour-gas, food-contact and special decompression requirements need their own qualification.
Structure and sizes:
AS568 enquiries by exact dash number; confirm grade and availability for the requested size.
Sizes: (ID × C/S) (mm)
Packing and shipping:
Standard export packing, inner plastic bag, outer with carton. Carton in pallets if necessary.
1: Express: DHL,UPS, TNT, FedEx, EMS ect, for urgent and small order.
2: Air shipment: air port to air port or air port to door.
3: Sea shipment: suitable for bulk goods. it will takes more longer time than air shipment.
The steps of the production:
Other relative rubber products for oil drilling use:
Company Profile:
Shanghai Qinuo Industry Co. Ltd supplies rubber, plastic and machined components to agreed drawings. Our ISO 9001 quality management supports specification review and inspection. O-ring orders should identify the groove dimensions, compound and hardness, installation conditions and sample acceptance criteria.
FAQ
Q1: Are you manufacture or trading company?
We are manufacture. Our factory located in Haimen District, Nantong City, Jiangsu Province.
Q2: How can we guarantee quality?
Agree the relaxed O-ring inside diameter, cross-section, dimensional tolerances and compound hardness inspection criteria. Check sample installation and seating against the intended groove and assembly procedure.
Q3: Can I get some samples?
Confirm sample availability, quantity, selected compound and shipping terms for the specified O-ring and installation-fit review with the quotation.
Q4: Can you produce OEM products?
Yes, we can produce by your samples or 3D drawings. We can build the molds and fixtures.
Q5: What's the term of payment ?
Amount < US$5000,100% paid in advance by paypal or T/T;
Amount >= US$5000, 30% paid in advance, 70% balance before shipment by T/T
Q6: Can you manage the shipment?
Sure, we can arrange different ship ways according to the goods final packing: by express, by air or by sea.
Q7: What is the lead time?
Stock goods: generally within 7days according to the quantity.
Produce Goods: 12-25days according to the packing and quantity.
