NBR Fig1502 Hammer Union Seals Nitrile Buna-N High Pressure Oil Resistant Seal Ring

Product   Description

Royal Way^® supplies hammer union seals for specified oilfield flow-line connections. Select the profile, compound and backing configuration against the union drawing and operating duty.

The catalogue includes Figure 1502, 602, 1002, 2002, and 2202 union references; confirm the manufacturer, size and seal seat before ordering. Working and test pressure limits require evidence for the exact complete union assembly. Available in Nitrile (NBR) for standard service, HNBR/FKM for specified compound requirements; sour-service suitability requires qualification of the exact formulation and assembly, and PTFE for specialized environments, backing options include brass or stainless steel where required by the approved seal configuration. Custom configurations, including non-standard sizes and hybrid material builds (elastomer + metal/PTFE), are tailored to meet unique operational needs.

Trust Royal Way ^® for durable, application-specific sealing solutions—contact our sales team to request a quote or discuss technical specifications for your project.

   Product    Show

NBR Figure 1502 Hammer Union Seals: Assembly Rating and Back-Up Selection

This listing references an NBR Figure 1502 seal. Provide the union manufacturer, nominal size and original seal number to confirm the rubber profile. Figure 1502 identifies a connection configuration; it is not sufficient by itself to assign a working or test pressure to a loose seal.

Match the outside diameter, inside diameter, height and lip geometry to the seal seat. Confirm whether the approved part is all rubber or includes a brass or stainless steel back-up. A backing change should be checked against the drawing and assembly requirements.

Include the fluid, temperature and any special service conditions when requesting the NBR compound. Alternative HNBR, FKM or PTFE configurations require separate confirmation of dimensions and duty. Inspect the union seat and replacement seal before fitting and follow the equipment maintenance procedure.

1" 1502, Buna / FKM/ HSN

1-1/2" 1502, Buna / FKM/ HSN

1-1/2" 1502, Buna / FKM/ HSN

3" 602/1502, Buna / FKM/ HSN(Brass/Stainless Anti-Ext)

4" 602/1002/1502, Buna / FKM/ HSN(Brass/Stainless Anti-Ext)

2" FIG 206, Buna / FKM/ HSN

3" FIG 206, Buna / FKM/ HSN

4" FIG 206, Buna / FKM/ HSN
