Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Product Details:
Place of Origin: Shanghai, China
Brand Name: SHQN
Certification: ISO9001
Model Number: HUS001
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Price: US$ 0.2-1
Packaging Details: bulking packing , standard carton
Delivery Time: 50000 pcs/ week
Payment Terms: T/T, Western Union
Contact Now
Detailed Product Description
Material: NBR (nitrile/Buna-N), HNBR/HSN, FKM Or PU Grade Per Drawing; PTFE Reviewed Separately Size: Custom Seal Dimensions And Tolerances Per Drawing; Nominal Connection Identified Separately
Pressure: Complete Union Assembly Rating And Service Specification Required Color: Black Or Customized Color
Nearest Port: Shanghai Custom: Dimensioned Section Drawing, Revision, Groove And Support Construction Required
Shape: Ring Profile And Section Per Approved Drawing Feature: Custom Profile And Compound Matched To Specified Fluid Service
Application: Oilfield Usage: For Hammer Union
Hardness: Specify Exact Elastomer Shore A Target And Tolerance; PTFE Reviewed Separately After-sales Guarantee: Yes, We Guarantee
Samples: Available In Stock: Confirm Availability Against Custom Drawing And Compound
Highlight:

hammer seal union

,

rubber lip seal

2" 3" 4" NBR nitrile FKM HSN HNBR Buna PTFE Hammer Union Seals



Application:



NBR nitrile hammer union seal rings are replacement sealing elements for compatible hose and pipe union connections used in oil-drilling equipment. Specify the nominal connection size, union figure and original seal drawing so that each ring matches its intended groove.

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Product Description



A hammer union comprises of a thread end, a nut end and a hammer nut which, when cinched up, compresses a composite seal assembly thereby preventing leakage. The seal assembly comprises a metal insert of a size to pass into the seal groove of conventional hammer unions and a small seal acting between the insert, the thread end and the nut end. The small seal is conveniently an O-ring or a Hammer Union Seal (Lip Seal) and is of a size that is compressed when the seal assembly is inserted into the thread end of the hammer union.



The hammer union is the complete metal connection; the seal ring is its replaceable sealing element. Figure references including 602, 1002, 1502, 2002 and 2202 require their own manufacturer drawing and groove confirmation. Seal rings must not be assumed interchangeable between figures.



Available size : 1", 2", 3", 4" and 5"



Material:



For a custom-size union seal, select one compound and hardness per drawing. NBR, nitrile and Buna-N identify the same polymer family; HNBR/HSN, FKM and PU are separate options. PTFE is a separate thermoplastic choice requiring its own design review.



Shanghai Qinuo Industry produced a full line of Hammer Union Seals.

For Figure 1502 replacement enquiries, match the seal profile and any brass or stainless steel support ring to the original connection drawing. Working pressure and proof-test requirements belong to the complete union assembly; confirm the manufacturer rating, service conditions and applicable test records. A seal material or nominal size alone does not establish a pressure rating.



Other seal enquiries; confirm material, figure and drawing for each item:

1" HAMMER UNION LIP SEAL RING, BUNA

1-1/2" HAMMER UNION LIP SEAL RING, BUNA

2" HAMMER UNION LIP SEAL RING, BUNA

3" HAMMER UNION LIP SEAL RING, BUNA

1" HAMMER UNION LIP SEAL RING,

1-1/2" HAMMER UNION LIP SEAL RING,

2" HAMMER UNION LIP SEAL RING,

3" HAMMER UNION LIP SEAL RING,

2" HAMMER UNION SEAL RING, BUNA W/ BRASS BACKING

3" HAMMER UNION SEAL RING, BUNA W/ BRASS BACKING

4" HAMMER UNION SEAL RING, BUNA W/ BRASS BACKING

2" HAMMER UNION SEAL RING, W/ BRASS BACKING

3" HAMMER UNION SEAL RING, W/ BRASS BACKING

4" HAMMER UNION SEAL RING, W/ BRASS BACKING

2" HAMMER UNION SEAL RING, BUNA W/ STAINLESS STEEL BACKING

3" HAMMER UNION SEAL RING, BUNA W/ STAINLESS STEEL BACKING

4" HAMMER UNION SEAL RING, BUNA W/ STAINLESS STEEL BACKING



Other relative rubber products for oil drilling use:

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Packing and shipping:

1: Express: S.F. ,DHL,UPS, TNT, FedEx ect, for urgent and small order.

2: Air shipment: air port to air port or air port to door.

3: Sea shipment: suitable for bulk goods. it will takes more longer time than air shipment.

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

Our company



Shanghai Qinuo Industry Co. Ltd

was established in 2003, is a new and high-tech enterprise integrating R&D, production and sales. Since its inception, we adhering to the "Quality for Survival, Innovation Competes For Development " concept, continuous development and innovation, we won a good reputation at home and abroad.

Our company provides professional plastic parts, rubber parts and maching parts design and production services, products mainly used in automobiles, household appliances, machinery equipment and oil industry and other fields. We have a professional production and sales team, "High-Quality, High Professionalism, High Efficiency" are the principles of doing things.

We have two factories, more than 30 injection molding machines, molding machines and CNC lathes. Our company is located in Pudong New Area, Shanghai. Elegant environment, convenient transportation, Only need 30 minutes from our company to Pudong Airport.

We adopt comprehensive quality management system, material-compliance documentation is reviewed against the specified product and order requirements, our products are mainly exported to the United States, Canada, Britain, Germany, Finland, New Zealand, Australia and other countries and regions.

Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material



The steps of the production:



Customized Size Hammer Seal Union NBR Nitrile FKM HSN HNBR Buna Material

www.unionseal.com

Welcome to contact us for more information.

Custom-Size Hammer Union Seals: Define Profile and Tolerances Before Material Selection

A custom union seal needs more than a nominal pipe size. Send the original union figure and a dimensioned section drawing identifying inner and outer diameters, height, lip or groove features and tolerances. Include any brass or stainless support ring as part of the agreed construction.

If using a replacement sample, identify its original part reference and service history. Confirm the finished dimensions against the mating groove; a worn or deformed sample alone cannot define the production drawing. Agree the drawing revision and sample-fit criteria before production.

Specify the compound grade, hardness and quantity after reviewing fluid composition, temperature and pressure cycling. Material aliases do not describe different products, and changing polymer does not by itself preserve fit or service suitability. Confirm the complete union assembly rating separately.
