Product Description:
Royal Way rubber O-rings are available for AS568 size enquiries and custom drawings. Silicone, NBR, FKM and EPDM are listed material options; select the exact compound for the medium and operating conditions. Specify the size, hardness and inspection requirements before ordering.
Environmental or regulatory requirements should identify the requested substance limits and supporting declaration for the selected compound. A material-family name alone does not establish environmental compliance.
Confirm the manufacturing route for the requested ring. A moulded endless O-ring and a cut or joined cord ring require different acceptance criteria; do not substitute one for the other without approval.
Custom identification should be agreed on packaging or labels. Any marking on the ring must be reviewed against the sealing surface and dimensional requirements.
Available in a wide range of colors, the Rubber O Rings product offers the flexibility to choose the color that best suits your needs. Whether you prefer a standard color for easy identification or a specific shade to match your branding, the custom color options for these O rings ensure that you can create a cohesive and personalized sealing solution.
For custom O-ring enquiries, provide the drawing or AS568 dash number, compound, hardness and operating medium. Confirm dimensional tolerance, inspection and packaging quantities in the quotation.
AS568 O-Ring Size and Compound Identification
Provide the AS568 dash number or the free-state inside diameter and cross-section with units. Confirm the gland drawing and whether the seal is static or moving. Keep size identification separate from compound identification: two rings with the same dimensions can have different fluid compatibility, hardness and temperature limits. For receiving inspection, request the agreed dimensional tolerance and batch identification. Colour can assist sorting but does not prove the material grade.
Applications:
Product Application Occasions and Scenarios:
AS568 is a dimensional size reference. Material suitability and application qualification must be reviewed separately for the following enquiry areas:
1. Industrial Machinery: Provide the gland dimensions, static or dynamic duty, operating temperature and pressure for compound and fit review.
2. Automotive Sector: Identify the exact fluid, component and temperature cycle. No universal pressure rating is assigned to all O-ring materials.
3. Aerospace Applications: State the required material specification, traceability and acceptance requirements. ISO 9001 describes the quality management system and does not establish aerospace product approval.
4. Plumbing and HVAC Systems: Confirm water, refrigerant, cleaning chemical or steam exposure. Select the compound for the actual medium and temperature; a general silicone option is not suitable for every service.
5. Medical Equipment: Provide the device contact conditions, cleaning or sterilisation method and required material documentation. Medical suitability requires application-specific confirmation.
6. Hydraulic Systems: Confirm fluid compatibility, gland clearance, movement and backup-ring requirements. Pressure capability depends on the compound and complete sealing arrangement.
OEM/ODM enquiries can cover size, compound and packaging identification. Confirm the applicable order quantity and application requirements with the quotation.
Support and Services:
Our Product Technical Support and Services for Rubber O Rings include:
- Assistance with installation and usage guidelines
- Troubleshooting and problem-solving support
- Recommendations for proper maintenance and care
- Information on material specifications and compatibility
- Warranty inquiries and claims processing
Packing and Shipping:
Product Packaging:
Confirm bag quantities, batch labels and carton requirements with the order. Keep different sizes and compounds separately identified to support receiving inspection.
Shipping:
Agree the dispatch date, destination, carrier and tracking availability with the quotation. Delivery timing depends on size, compound, order quantity and production scheduling.
