TA Swab Cups for 2.875-inch Tubing References and Sand-Bearing Service
For medium-load sand-bearing service in the 2.875-inch tubing size reference, specify the TA replacement cup profile and actual tubing bore. The existing 2-7/8-inch catalog rows list a 2.431-inch cup OD and 1.370-inch cup ID for steel or aluminum cores; confirm these dimensions, height and mandrel fit against the individual drawing. The specified aluminum or steel bushing must match the individual cup drawing. Provide fluid composition, sand content and temperature to select the compound; tubing size alone does not establish fit or load capacity.
| Nom. OD (inch) |
Core and Description |
Cup OD |
Cup ID |
| 2-3/8" (2") |
Aluminum Core Swab Cup |
1.992" |
1.120" |
| 2-3/8" (2") |
Steel Core Swab Cup |
1.992" |
1.120" |
| 2-7/8" (2-1/2") |
Aluminum Core Swab Cup |
2.431" |
1.370" |
| 2-7/8" (2-1/2") |
Steel Core Swab Cup |
2.431" |
1.370" |
| 3-1/2" (3") |
Aluminum Core Swab Cup |
2.985" |
1.370" |
| 3-1/2" (3") |
Steel Core Swab Cup |
2.985" |
1.370" |
Our Swab Cups are produced from a selected nitrile or other specified compound for the required cup profile. Confirm compound compatibility and service limits for the fluid formulation. The size table is a catalog reference; match profile, height, OD and ID to the replacement drawing.
Available types of Swab cups:
TA style: A medium-load cup built around a steel or aluminum bushing. Confirm the tubing bore, mandrel fit and required load range before selecting the cup; compound and dimensions must match the actual well conditions.
V style: V cups are offered in different configurations. Confirm the required all-rubber or reinforced design from the drawing. Cup arrangement, load response and sand-bearing fluid suitability depend on geometry and operating conditions; provide the fluid formulation, additives, solids content and temperature for compound selection.
TUF style: A cup with internal metal reinforcement to help maintain its profile. Confirm tubing condition, bore restrictions, required load and compound temperature limits before selection.
NUF style: A heavy-load rubber cup bonded to a steel or aluminum bushing. Confirm the exact size, bushing dimensions, mandrel connection and fluid conditions for the intended swabbing operation.
| Part Name |
MV Style, TA style, TUF style, NUF style and V style |
|
Environment
|
oil, gas, gas condensate
|
|
Available Material
|
Nitrile (NBR), HNBR or FKM options; reinforcement and compound per confirmed cup drawing
|
Other relative rubber products:
Packing and shipment:
1: Express: S.F. ,DHL,UPS, TNT, FedEx ect, for urgent and small order.
2: Air shipment: air port to air port or air port to door.
3: Sea shipment: suitable for bulk goods. it will takes more longer time than air shipment.
