| Place of Origin: | Shanghai, China |
| Brand Name: | SHQN |
| Certification: | ISO9001 |
| Model Number: | 4" |
| Minimum Order Quantity: | 1000pcs |
|---|---|
| Price: | EXW US$ 0.2-1 |
| Packaging Details: | CARTONS PACKING |
| Delivery Time: | 20DAYS |
| Payment Terms: | L/C, D/A, T/T, Western Union |
| Supply Ability: | 10000PCS PER WEEK |
| Material: | Polyurethane/TPU Grade For This Enquiry; NBR/FKM/HNBR Alternatives By Review | Hardness: | Original 80 Shore A Reference; Confirm Target And Tolerance |
|---|---|---|---|
| Using: | Oil Gas Field | Other Sizes: | Original 2, 3, 4 Inch References; Exact Seal Dimensions By Drawing |
| Color: | Purple Or Customized Color | Key Words: | Fig 1502 Purple Polyurethane Seal Ring |
| Highlight: | Polyurethane Rubber Seal Ring,FIG 1502 Rubber Seal Ring,Oil Gas Field Rubber Seal Kits |
||
4-Inch Figure 1502 Purple Polyurethane Seal Ring
The purple polyurethane seal ring is listed against a 4-inch Figure 1502 reference. Confirm the equipment manufacturer and sealing location before selecting a replacement; figure number and colour alone do not establish fit or material grade.
| Selection detail | Information to provide |
|---|---|
| Fit | Equipment reference, seal part number, cross-section and mating groove dimensions. |
| Material | Required polyurethane or TPU grade. NBR, FKM and HNBR are separate alternatives requiring review. |
| Hardness | Original 80 Shore A reference; agree target hardness and tolerance for the selected grade. |
| Duty | Fluid, cleaning agents, temperature and complete equipment operating requirements. |
The seal has no independent pressure rating. Use the equipment manufacturer inspection, installation and testing procedures. AS568 sizes apply only to separately specified round-section O-rings and do not define this profiled ring.
Original size references: 2, 3 and 4 inches. This enquiry focuses on the 4-inch reference; confirm nominal equipment size and actual seal dimensions from the drawing.
![]()
Other related products (ordered separately):
Related wireline packaged kit references (ordered separately):
• #10 setting tool - With burst disk
• #20 setting tool - With burst disk
• AP Compact Setting Tool Kit
• Grease Tubes Seal Kit
• 3 1/2” Shorty Kits
• 3 - 1/8" Weight Bar Kit
• #10 Baker Firing Head Kit
• #20 Firing Head Kit
• #20 BP3.SEC kits
• #10 BP3.SEC kits
• T-BRT redress kit
• T-1 Set
• GC Stripper Head Redress Kits
Note: Bleeder disc options apply to the relevant wireline kit; confirm its specified bill of materials.
Wireline Component Parts:
1) Pressure Relief Disc, ZD Plated (application:rupture(bleeder) Disc)
2) Rubber Push Pin -black
3) Nylon Push Pin -natural
4) Retainer Nut, Steel, ZD Plated (Flat, beveled also available) (application: retainer nut)
5) Threaded Steel Plug, w/ Lathe Cut (application:5" port plug)
6) Threaded Brass Plug (application: setting tool plug )
Oilfield Plug Valve Seals products data sheet
| Available sizes | 1" 2" 3" |
| Available material | NBR HNBR FKM with Brass or SS backside |
| Hardness | 80 Shore A or 90 Shore A |
| Types | Y type |
Hammer union seals:
Hammer Union Seals are used in hammer union-style pipe connections to establish flow lines and prevent leakage.
Available size : 1", 2", 3", 4" and 5"
Material enquiries for related hammer union seals include NBR, HNBR and FKM grades or PTFE designs by specification. Review the actual fluid and temperatures with the selected grade. HNBR alone does not establish sour-gas qualification. Brass or stainless backup arrangements must match the approved union drawing.
Swab cups:
Related swab cups are ordered separately from this 4-inch Figure 1502 polyurethane seal ring. A swab cup seals against the tubing or casing bore during fluid recovery. Select the cup profile, outside diameter, mandrel bore, core arrangement and compound for the actual tubing inside diameter, fluid exposure and permitted fluid-column load. Use the selected cup and mandrel operating instructions when assessing the application.
MV Style, TA style, TUF style, NUF style and V styles.
Rubber o rings or kits
Shanghai Qinuo accepts AS568 O-ring enquiries by dash number and compound grade. Confirm tooling and availability for the exact sizes.
Color, hardness, packing all can be custom making.
Other oil field rubber and plastic fittings:
Rubber packer elements
Thread protectors
Flow tubes
Other parts by drawing.
![]()
![]()
Shanghai Qinuo Industry Co. Ltd
We operate an ISO 9001 quality management system. For polyurethane seal enquiries, agree the equipment reference, drawing, compound grade and inspection requirements. Confirm tooling, production availability and delivery with the quotation.
Our Service capability:
| Customized services | Plastic & Rubber bonding | Mold Design | ||||||
| Customized extrusion | Extrusion and bonded gaskets | Mold Production | ||||||
| Injection Molding | Self Adhesive rubber profile | Customized Package | ||||||
| Sheet Cutting | Rubber Complex Intake Hose | Problem Solving | ||||||
| Standard Size extrusion | Reinforced rubber tubes | Assembly | ||||||
| Special Compound design | Rubber Solution Suggestion | Sourcing | ||||||
| Rubber& Metal bonding | ||||||||
