| Place of Origin: | Shanghai, China |
| Brand Name: | SHQN |
| Certification: | ISO9001 |
| Model Number: | Plastic Thread Protectors |
| Minimum Order Quantity: | 1000 |
|---|---|
| Price: | 0.1-0.3 |
| Packaging Details: | Standard export packing |
| Delivery Time: | Depends on order qty |
| Payment Terms: | L/C, T/T, Western Union, , D/A, D/P |
| Supply Ability: | 5 tons/week |
| Material:: | Polypropylene (PP); Grade To Be Agreed | Color: | Black, Or Assigned Color |
|---|---|---|---|
| Application: | Matching Steel Pipe Connection Transport And Storage | Product Name: | 3-1/8 Inch Reference PP Pipe Thread Protectors |
| Shape: | Pin Or Box Geometry; Pipe Family And Dimension Meaning By Drawing | Quality: | ISO 9001 Quality Management; Acceptance Requirements By Order |
| Style: | Pipe Thread Protectors | Service: | Drawing Review And Specification-based Quotation |
| Mode Of Production: | Molded PP; Tooling By Approved Connection Design | Business Type: | Manufacturer/Factory |
| Package: | Packing Identified By Drawing Reference, Connection And End | Use: | Pipe Thread Protection During Transport And Storage |
| Sample: | Available,7-10 Workdays | Logo: | Size Reference, Connection And Batch Marking By Agreement |
| Machine Type: | Drilling Tool | Surface Finish: | Molded Finish; Engagement Surfaces Per Approved Drawing |
| Design Software: | UG, Pro/E, CAD, Solidworks And So On | ||
| Highlight: | oilfield thread protectors,drill pipe thread protectors |
||
This PP pipe thread protector enquiry uses a 3-1/8 inch size reference. Identify that dimension on the drawing and confirm whether the protected connection belongs to casing or drill pipe before ordering. The protector covers a matching threaded steel pipe end during transport and storage; the steel pipe material does not change the listed polypropylene (PP) protector material. A quotation should follow the approved geometry and quantity rather than a general low-price description.
Quotation details: 3-1/8 inch reference, PP material, black or agreed color, pipe family, full connection designation and pin or box end. Confirm engagement length, seating clearance and required coverage from the drawing. BTC, STC and LTC casing references differ from NC26, NC38, NC50 and REG drill pipe references. The wider 2-3/8 to 20 inch nominal range requires separate availability review and does not establish this item fit.
![]()
![]()
![]()
![]()
![]()
![]()
Packaging & Shipping
| Port: | Shanghai |
| MOQ: | 1000 pcs,Custom parts: 5000pcs |
| Packing: | bulk packing or custom packing |
| Payment: | Payment method to be agreed in the quotation. |
| Delivery time: | Delivery schedule to be agreed after drawing review, tooling and quantity confirmation. |
![]()
![]()
Other oil and gas industry accessories for choice:
![]()
Our company
![]()
Shanghai Qinuo supplies molded plastic parts and oilfield accessories. For this 3-1/8 inch reference protector, send a marked connection drawing so the pipe family, size meaning and fit can be reviewed before quotation.
A useful comparison of offers uses the same connection, PP grade, coverage and acceptance requirements. Include tooling, sample approval and packing requirements where applicable.
Agree the molded dimensions, material grade, color and marking on the approved drawing. Review any tooling requirement separately from the recurring part quantity.
ISO 9001 applies to the quality management system. Fit, handling and environmental requirements should be specified for the ordered design rather than inferred from price or a nominal size label.
![]()
FAQ
1. What does the 3-1/8 inch reference identify?
Its meaning must be confirmed on the drawing; it may refer to a pipe, connection or protector dimension.
State casing or drill pipe and provide the full connection designation. Do not select a protector solely from the size reference.
2. What makes quotations comparable?
a. The same pipe family and approved connection drawing.
b. Matching pin or box orientation and quantities.
c. The same PP grade and color requirements.
d. Agreed coverage, engagement and clearance dimensions.
e. Equivalent sample and acceptance checks.
f. Clearly stated tooling and marking requirements.
g. Packing, delivery schedule and commercial terms agreed in the quotation.
3. What should be approved before a repeat order?
1. Confirm the drawing and revision remain applicable.
2. Check whether the pipe connection or protector construction has changed.
3. Identify the required material and color.
4. Confirm markings and packing by connection.
5. Review sample fit again if critical geometry or material changes.
4. How should protectors be inspected after receipt?
1. Compare item identification and quantities with the order.
2. Inspect for cracks, distortion and damaged engagement.
3. Verify starting engagement and seating on the intended end.
4. Check required coverage and removal.
5. Segregate mismatched or damaged items rather than forcing fit.
Other nominal sizes and oilfield accessories require separate drawings and quotation specifications.
Send the marked 3-1/8 inch reference drawing, pipe connection and order quantities for a PP protector quotation.
